Sun[tm] Storage 6780 Parts Number - Sales or Technology

Sun[tm] Storage 6780 Parts Number - Sales or Technology -->技术服务-->联系-->霍工-->13301272832(微信同号)
Table Legend
[F] = Field Replaceable Unit (FRU)
[C] = Customer Replaceable Unit (CRU)
[S] = Supported, but can no longer be ordered with this system
[N] = No longer supported for this system
Price = Price this Part

Array Controller
Option # Manufacturing
Part #		 Description Previous
Part #
n/a 375-3336 [F] FC Expansion I/O Module, L n/a
n/a 540-7798 16GB Controller Module n/a
  • 4GB USB Flash
 n/a
  • 4Gbps Fibre Channel Host Card
n/a
  • 1GB DIMM
 n/a
  • Base Board with 2GB DIMM
 n/a
n/a 540-7805 8GB Controller Module n/a
  • 4GB USB Flash
 n/a
  • 4Gbps Fibre Channel Host Card
n/a
  • 1GB DIMM
 n/a
  • Base Board with 2GB DIMM
 n/a
n/a 540-7935 16GB RAID Controller Module n/a
  • 4GB USB Flash
 n/a
  • 1GB DIMM
 n/a
  • Base Board with 2GB DIMM
 n/a
  • 8Gbps Fibre Channel Host Card
 n/a
n/a 540-7936 16GB RAID Controller Module n/a
  • 4GB USB Flash
 n/a
  • 1GB DIMM
 n/a
  • Base Board with 2GB DIMM
 n/a
  • 8Gbps Fibre Channel Host Card
 n/a
n/a 542-0320 32GB RAID Controller Module n/a
  • 4GB USB Flash
 n/a
  • 371-4879 [F]
  • 2GB Cache Memory DIMM
 n/a
  • Base Board with 2GB DIMM
 n/a
  • 8Gbps Fibre Channel Host Card
 n/a
n/a 542-0322 64GB RAID Controller Module n/a
  • 371-4880 [F]
  • 4GB Cache Memory DIMM
 n/a
  • 371-4881 [F]
  • 8GB USB Flash
 n/a
  • Base Board with 2GB DIMM
 n/a
  • 8Gbps Fibre Channel Host Card
 n/a
Backplane/Centerplane
Option # Manufacturing
Part #		 Description Previous
Part #
n/a 540-6545 Drive Cage Midplane, n/a
Cables
Option # Manufacturing
Part #		 Description Previous
Part #
n/a 560-2727 Ship Kit n/a
  • 180-2404
  • IEC 320 C13 to IEC 320 Sheet E, 10A/250V, 1.0M
 n/a
  • 371-1107 [F]
  • DB-9F / RJ-45 Serial Adapter,
n/a
  • RJ45F to DB9F Adapter,
n/a
  • 530-3879 [F]
  • RJ45 to RJ45 Shielded Ethernet Cable, CAT5, 2M,
n/a
  • 537-1082 [F]
  • Fibre Channel Optical Cable LC/LC, 5M,
n/a
Disks
Option # Manufacturing
Part #		 Description Previous
Part #
n/a 390-0258 Fujitsu MAW3300FC [MAW3300FCSUN300G]
(300GB - 10000 RPM - FC-AL Disk), 		n/a
n/a 390-0330 Seagate ST3300655FC [ST330055FSUN300G]
(300GB - 15000 RPM - FC-AL Disk), 		n/a
n/a 540-6548 [C] 73GB - 15000 RPM FC-AL, Disk Assembly with one of the following disks:, n/a
  • Seagate ST373554FC [ST373554FSUN72G]
    (73GB - 15000 RPM - FC-AL Disk),
n/a
  • Fujitsu MAX3073FD [MAX3073FDSUN72G]
    (73GB - 15000 RPM - FC-AL Disk),
n/a
  • Seagate ST373455FC [ST373455FSUN72G]
    (73.4GB - 15000 RPM - FC-AL Disk),
n/a
  • Drive Mounting Bracket (HDD Carrier),
n/a
n/a 540-6549 [C] 146GB - 10000 RPM FC-AL, Disk Assembly with one of the following disks:, n/a
  • Fujitsu MAW3147FC [MAW3147FCSUN146G]
    (146GB - 10000 RPM - FC-AL Disk),
n/a
  • Hitachi HUS1014FA [HUS1014FASUN146G]
    (146GB - 10000 RPM - FC-AL Disk),
n/a
  • Seagate ST3146707FC [ST314670FSUN146G]
    (146GB - 10000 RPM - FC-AL Disk),
n/a
  • Drive Mounting Bracket (HDD Carrier),
n/a
n/a 540-6550 [C] 146GB - 15000 RPM FC-AL, Disk Assembly with one of the following disks:, n/a
  • Seagate ST3146954FC [ST314695FSUN146G]
    (146GB - 15000 RPM - FC-AL Disk),
n/a
  • Fujitsu MAX3147FD [MAX3147FDSUN146G]
    (146GB - 15000 RPM - FC-AL Disk),
n/a
  • Seagate ST3146855FC [ST314655FSUN146G]
    (146GB - 15000 RPM - FC-AL Disk),
n/a
  • Seagate ST3146356FC [ST314656FSUN146G]
    (146GB - 15000 RPM - FC-AL Disk),
n/a
  • Drive Mounting Bracket (HDD Carrier),
n/a
n/a 540-6551 [C] 300GB - 10000 RPM FC-AL, Disk Assembly with one of the following disks:, n/a
  • Hitachi HUS1030FA [HUS1030FASUN300G]
    (300GB - 10000 RPM - FC-AL Disk),
390-0258
  • Seagate ST3300007FC [ST330000FSUN300G]
    (300GB - 10000 RPM - FC-AL Disk),
n/a
  • Drive Mounting Bracket (HDD Carrier),
n/a
n/a 540-6635 [C] 500GB - 7200 RPM SATA, Disk Assembly with one of the following disks:, n/a
  • Hitachi HDS725050KLA360 [HDS7250SASUN500G]
    (500GB - 7200 RPM - SATA Disk)
 n/a
  • Seagate ST3500630NS [ST35000NSSUN500G]
    (500GB - 7200 RPM - SATA Disk)
 n/a
  • Hitachi HUA721050KLA330 [HUA7250SBSUN500G]
    (500GB - 7200 RPM - SATA Disk)
 n/a
  • 541-1406
  • Drive Mounting Bracket (SATA HDD Carrier),
n/a
n/a 540-7156 [C] 300GB - 15000 RPM FC-AL Disk Assembly with one of the following disks:, n/a
  • Seagate ST3300656FC [ST330056FSUN300G]
    (300GB - 15000 RPM - FC-AL Disk),
n/a
  • Seagate ST3300657FC [ST330057FSUN300G]
    (300GB - 15000 RPM - FC-AL Disk),
n/a
  • Hitachi HUS156030VLF400 [HUS1530FCSUN300G]
    (300GB - 15000 RPM - FC-AL Disk),
n/a
  • Seagate ST3300655FC [ST330055FSUN300G] (300GB - 15000 RPM - FC-AL Disk)
 390-0330
  • Drive Mounting Bracket (HDD Carrier),
n/a
n/a 540-7245 [C] 750GB - 7200 RPM SATA Disk Assembly with one of the following disks, n/a
  • Seagate ST3750640NS [ST37500NSSUN750G]
    (750GB - 7200 RPM - SATA Disk)
 n/a
  • Hitachi HUA721075KLA330 [HUA7275SASUN750G]
    (750GB - 7200 RPM - SATA Disk)
 n/a
  • 541-1406
  • Drive Mounting Bracket (SATA HDD Carrier),
n/a
n/a 540-7590 [C] 1TB - 7200 RPM SATA, Disk Assembly with one of the following disks: n/a
  • Hitachi HUA721010KLA330 [HUA7210SASUN1.0T]
    (1TB - 7200 RPM - SATA Disk)
n/a
  • Seagate ST31000340NS [ST31000NSSUN1.0T]
    (1TB - 7200 RPM - SATA Disk)
 n/a
  • Seagate ST31000524NS [ST31001NSSUN1.0T]
    (1TB - 7200 RPM - SATA Disk)
 n/a
  • Seagate ST1000NM0011 [ST1000NM0011](1TB - 7200 RPM - SATA Disk)
 n/a
  • 541-1406
  • Drive Mounting Bracket (SATA HDD Carrier),
n/a
n/a 540-7674 [C] 450GB - 15000 RPM FC-AL, Disk Assembly with one of the following disks:, n/a
  • Seagate ST3450856FC [ST345056FSUN450G]
    (450GB - 15000 RPM - FC-AL Disk),
n/a
  • Drive Mounting Bracket (HDD Carrier),
n/a
n/a 542-0163 [C] 600GB - 15000 RPM FC-AL, Disk Assembly with one of the following disks and brackets:, n/a
  • Seagate ST3600957FC [ST360957FSUN600GB]
    (600GB - 15000 RPM FC-AL),
n/a
  • Hitachi HUS156060VLS401 [HUS1561FCSUN600G]
    (600GB - 15000 RPM FC-AL),
n/a
  • Drive Mounting Bracket (HDD Carrier),
n/a
n/a 542-0164 [C] 2TB - 7200 RPM, Disk Assembly with 1 bracket and 1 disk:, n/a
  • Hitachi H7220AA30 [H7220AA30SUN2.0T]
    (2TB - 7200 RPM - SATA Disk)
 n/a
  • Seagate ST32000644NS [ST32000NSSUN2.0T]
    (2TB - 7200 RPM - SATA Disk)
 n/a
  • Seagate ST2000NM0011 [ST2000NM0011] (2TB - 7200 RPM - SATA Disk)
 n/a
  • 541-1406
  • Drive Mounting Bracket (SATA HDD Carrier),
n/a
n/a 542-0321 [C] 73GB Solid-State Drive FRU n/a
  • 542-0325
  • 73GB Solid-State Drive Tray
 n/a
  • 73GB Zeus Solid-State Drive
 n/a
Fibre Channel
Option # Manufacturing
Part #		 Description Previous
Part #
7100822 4 × 8Gbps Short Wave SFPs, X-Option
7048837 [F] 8Gbps Short Wave SFP 371-4582 [F]
n/a 371-1799 [F] 4Gbps Short Wave SFP, n/a
n/a 371-4371 [F] 4Gbps Fibre Channel Host Card n/a
n/a 371-4582 [F] 8Gbps Short Wave SFP n/a
n/a 375-3626 [F] Base Board with 2GB DIMM n/a
n/a 375-3627 [F] 8Gbps Fibre Channel Host Card n/a
Memory
Option # Manufacturing
Part #		 Description Previous
Part #
XTA6780-DIMM32-UPG 556-4450 32GB DIMM Upgrade n/a
  • 4GB USB Flash
 n/a
  • 371-4879 [F]
  • 2GB Cache Memory DIMM
 n/a
XTA6780-DIMM64-UPG 556-4451 64GB DIMM Upgrade Kit n/a
  • 371-4880 [F]
  • 4GB Cache Memory DIMM
 n/a
  • 371-4881 [F]
  • 8GB USB Flash
 n/a
n/a 371-4372 [F] 1GB DIMM n/a
Miscellaneous
Option # Manufacturing
Part #		 Description Previous
Part #
n/a 541-3528 [F] Front Bezel n/a
Power
Option # Manufacturing
Part #		 Description Previous
Part #
n/a 300-2319 [F] 620 Watt AC Input Power Supply (CSM200), L n/a
n/a 371-4373 [F] Interconnection Module n/a
n/a 371-4374 [C] Battery Backup Module n/a
n/a 371-4375 [C] 525 Watt AC Input Power Supply n/a
Rack
Option # Manufacturing
Part #		 Description Previous
Part #
XTA6000-RK2-RAIL 594-5885 Rack Rail Kit for Sun Rack II, n/a
  • 540-7796
  • Mounting Rail Kit,
n/a
    • 341-4881
    • Mounting Rail,
n/a
XTA6X80CTRL-RK2-RL 542-0150 Fixed Rail Mounting Kit, n/a
  • 341-4882
  • Mounting Rail,
n/a
  • 341-4883
  • Mounting Rail,
n/a
XTA6000KRM-RK-RL [S] 350-1532 Rack Rail Kit for Sun Rack II, n/a

Table Legend
[F] = Field Replaceable Unit (FRU)
[C] = Customer Replaceable Unit (CRU)
[S] = Supported, but can no longer be ordered with this system
[N] = No longer supported for this system
Price = Price this Part

Exploded View

No Artwork Currently Available

Table Legend
[F] = Field Replaceable Unit (FRU)
[C] = Customer Replaceable Unit (CRU)
[S] = Supported, but can no longer be ordered with this system
[N] = No longer supported for this system
Price = Price this Part
NS = Not Shown

Code Manufacturing Part# Description
NS 540-6543 CSM 200 Chassis Assembly, L
  • 620 Watt AC Input Power Supply (CSM200), L
  • 540-6545
  • Drive Cage Midplane,
NS
  • 540-6546
  • Chassis,

中国·北京 联系方式：
1）联系人： 　 霍经理
2）手　机：　13301272832 (微信同号)
3）QQ: 619804118
4）联系电话：（010）82666745
5）传　 　真：（010）82666745
6）E-mail: 　　bjslkc@163.com
7）公司：北京深蓝融鑫科技发展有限公司
8）地址：北京市海淀区西北旺
9）公司地址、乘车路线及公司位置地图


Beijing ShenLan Rongxin Technology Development Co., Ltd. All Rights Reserved.
北京深蓝融鑫科技发展有限公司 版权所有,不得转载.
京ICP备05042544号
